Automatic Four Sides Bag Sealing KF94 3D Face Mask Packing Machine 120 Pcs Per Min
Contact Person : Hebe
Phone Number : 0086-18217495276
WhatsApp : +008618217495276
|Minimum Order Quantity :||1 set||Price :||negotiable|
|Packaging Details :||Sea-Worthy Packing or Air-Worthy Packing||Delivery Time :||30 days|
|Payment Terms :||L/C, T/T||Supply Ability :||10 pcs per month|
|Place of Origin:||China||Brand Name:||Haitel|
|Certification:||CE SGS ISO||Model Number:||HTL-480A|
|Packing Speed:||100~300 Bags/min||Membrane Width:||≤480mm|
|Voltage:||380V/50Hz||Total Power:||4 KW|
|Motor Power:||1.5 KW||Heating Power:||2.5 KW|
200Bags/Min Horizontal Flow Pack Machine,
480mm Membrane Horizontal Packaging Machine,
380V Horizontal Packaging Machine
200 bags/min automatic Plastic Film Horizontal Flow Packing Machine For fruit and vegetable
Full computer controlled, frequency conversion controls speeding, high detective photoelectric device, independent sealing temperature control, applicable to many packaging material, mechanical simplicity, easy to maintenance, low wearing, long service life. Feeding paper from bottom, it has push feeder (HTL-480A) and membrane feeder (HTL-480B) types.
It is applicable to special packing for soft and long products like instant noodle, wet tissue, bread, meet, chicken meet, dried noodle, egg roll, soft candy, fresh fruit and towel.
Main technical parameter
|Making-bag size||(L)=70~360mm, (W)=30~120mm, (H)=3~50mm|
|Packing speed||100~300 bags/min|
|Total power||4 KW|
|Motor power||1.5 KW|
|Heating power||2.5 KW|
|Dimension (L*W*H)||4800×950×1150 mm|
|Total weight||1000 kg|
HTL-480 Main collocate
①PLC and touch screen: Taiwan
② Photoelectricity switch: Yatai
③ Transducer: Yatai
④ Push button: Delixi
⑥ Temperature controller: Delixi
⑦Approach switch: Delixi
HTL-480 spare parts list (FREE)
1. Electric heating tube 2
2. Electric heating circle 1
3. Electric thermal couple 1
4. Conveying claw 5
5. Cutting knife 2
6. Internal hexagonal spanner 1
7. Oil gum 1
8. Opening spanner 1
9. Certificate of inspection 1
10. Manual 1
1.Confirm machine type: Negotiate with clients to seclect the correct machine according to customers’ requirment.
2.Quote and Sign firm contract: After confirm with customers with all details, such as payment terms, model, delivery time, send official quotation to clients.
1.When equipments arrive in clients factory,send engineers there for installation and ensure customers know how to operate the machine.
2.In order to improve our products,we keep in close contact with customers to know their feedbacks and suggestions.
3.From the date of the buyer receive the machines, free warrant for 12 months.
Packaging and Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
The quality of the production line will have 12 month warranty since the installtion in the buyer's factory.
WHY CHOOSE US?
• Top Food machine manufacturer in China
• 20000 square meters production plants
• Over 22 years of experience
• Made-in-China’s Gold member since 2009
• CE, ISO9001 certified
• Engineers able to offer overseas installation and testing, and training.The plant layout design, assembling, installation and debugging, start-up and local team training will be FREE at no cost.
• Prompt delivery and flexible payment terms
• Small order is welcomed
• professinal team with strong technical and R&D knowledge to develop advanced food equipments
• save labor cost and improve the capacity.
