Detail Information

Product Name: AUTOMATIC KN95 MASK MACHINE Equipment Size: 10050mm(L)×1500mm(W)×2200mm(H)
Equipment Weight: ≤2800kg, Ground Bearing≤300KG/m2; Working Power: Equipment380VAC±5﹪,50HZ, Rated Power 9KW;
Compressed Air: 0.5~0.7 MPa, Use Flow Is About20000L/min Productivity: 25-70PCS/MIN
High Light:

Kn95 Nonwoven Mask Making Machine

,

20000L/Min Kn95 Mask Machine

Product Description

AUTOMATIC KN95 MASK MACHINE



Introduction of raw material selection:



KN95 is a six-layer fabric structure, the outer layer is skin-friendly non-woven fabric, built-in PP cotton and double-layer electrostatic adsorption melt-blown filter element, to filter particles with aerodynamic diameter of 0.24 ± 0.6μm (physical diameter 0.075µm ± 0.020µm) The efficiency reaches more than 95%.

After production, it shall be sterilized by ethylene oxide and allowed to stand for 7 days for volatilization toxicity. After being sealed and packed, it shall be shipped out in a box.

Six Layer Fabric 20000L/Min Kn95 Nonwoven Mask Making Machine 0

This module is a raw material placement unit. N95 masks are generally composed of 3-6 layers of fabric (see the mask picture above for details). As you can see, this mask machine can make up to 6 layers of masks. When you need to make a few layers of masks, just put a few rolls of fabric on the rack and leave the rest empty.





It mainly realizes the automatic feeding of the fabric, the integration of multi-layer fabric folding and the layered folding, and the fabric is compressed after being folded.

Six Layer Fabric 20000L/Min Kn95 Nonwoven Mask Making Machine 1

The module mainly includes a fabric stacking structure, a nose bridge line placement structure, a breathing valve cutting structure and waste collection.





The main purpose is to put the nose bridge line into the fabric of the mask after cutting, and obtain the surface contour through the embossing device

Six Layer Fabric 20000L/Min Kn95 Nonwoven Mask Making Machine 2

The module mainly includes left and right pad printing structure, ear strap cutting structure, labeling structure, feeding structure and folding device.

Mainly realize the functions of text printing on the surface of the mask, fixed-point shear welding of the earband, labeling and folding the mask in half.

Six Layer Fabric 20000L/Min Kn95 Nonwoven Mask Making Machine 3

The module mainly includes a mask feeding flattening mechanism, a mask cutting mechanism output structure and an automatic waste recycling mechanism.





It mainly realizes automatic feeding of ear straps, fixed cutting, and placing the cut ear straps in the position specified by the plane mask. The equipment automatically completes the ultrasonic welding of the ear straps and mask.
